Servos are powered by the ESC’s output to the receiver. If you’re using a higher-strength servo than the ESC can support (usually greater than 20kg), you may experience ‘brown-outs’ where the radio signal can be interrupted and cause erratic driving. This can be helped by plugging a Glitch Buster into the receiver smoothing the current delivery. However, in some cases, you may need to install an external BEC.
- Total Height (A) = 67.8mm
- Body Width (B) = 60mm
- Below Mount (C) = 48mm
- Above Mount (D) = 17mm
- Total Length (E) = 75mm
- Total Width (F) = 30mm
Specifications
| Servo | |
|---|---|
| Servo Size: | 1/5 |
| Servo Spline Count: | 17 |
| Drive Motor Type: | Brushed |
| Waterproof Casing: | No |
| Gear Material: | Metal |
| Torque kg/cm: | 65 |
| Signal Type: | Digital |
| Case Material: | Plastic, Aluminium |
| Rotational Degrees: | 120o (Normal) |
| 6.0v Sec/60 Degrees: | 0.21 |
| “A” Measurement: | 67.8 |
| “B” Measurement: | 60 |
| “C” Measurement: | 48 |
| “D” Measurement: | 17 |
| “E” Measurement: | 75 |
| “F” Measurement: | 30 |
